PACKAGING MACHINE F1000 + VOLUMETRIC BELT DOSER DT10


PACKAGING MACHINE F1000 + VOLUMETRIC BELT DOSER DT10


FROM 5 TO 30 kg

Packaged products: sand, lapillus, perlite, gravel etc.

Technical Data

MEC Version

Bag weight/volume From 5 to 30 kg
Maximum bag size 470x680 mm
Weighing/dosing system Belt doser DT10
Maximum reel width 980 mm
Capacity From 10 to 16 bags/min
Type of welding Impulse
Type of bag Pillow/with gusset
Sealing groups movement MECHANICAL
Power consumption 6 Kw
Frame Painted Steel or
Stainless Steel 314-316


SYNCRO Version

Bag weight/volume From 5 to 30 kg
Maximum bag size 470x680 mm
Weighing/dosing system Belt doser DT10
Maximum reel width 980 mm
Capacity From 18 to 24 bags/min
Type of welding Impulse
Type of bag Pillow/with gusset
Sealing groups movement with BRUSHLESS Motor
Power consumption 10 Kw
Frame Painted Steel or
Stainless Steel 314-316



* ECO or SEMI-AUTOMATIC version available on demand
